| BONNET ASSLY. FEATURES : |
| Design |
| Screwed bonnet |
| Bonnet |
| Back seat blowout proof |
| Stem |
| Rolled stem operating threads. |
| Stem tip |
| Self centering non rotating, rotating, regulatingand soft seated |
| Bonnet Pusher |
| Silver plated for anti galling freezing for increased stem cycle life |
| Dust Cap |
Protects stem threads from ingrease of contamination.
Colour coded identification. |
| Handle |
| Low torque operating |
| Sealing |
| Leak tight seal for easy operation of valve. |
| SPECIFICATIONS : |
| Size |
1/4", 3/8", 1/2" |
| End ports |
NPT, BSPT, socket weld |
| Process flange size |
1/2",3/4",1",1-1/2", 2" |
| Flange pressure rating |
150#, 300#, 600#, 900#, 1500#, 2500# |
| Flange end |
Raise Face. Ring Joint |
| Bleed port |
1/4", 3/8", 1/2" |
| Version |
Straight & angle |
| Max. Std. Pressure |
6000 Psi (413 Bar) |
| Temperature Rating |
PTFE 450° F (232° C)
Grafoil 700° F (371° C) |
| Material |
SS 316, SS 304, C.S., F11, Hastelloy, Monel |
| Standard seat |
Ø4mm |
| Panel mount option |
All valves are 100% Factory tested prior to shipment. |
|
